Kitchen Lift Elevator Manufacturers

Capacity

20 – 500 kgs.

Application

Hotels, Restaurants, Hospitals, Educational Institutes, Libraries, Banks, Showrooms, Hostels or Private Bungalows.

Speed

0.25 m/s

Kitchen lift elevators are compact vertical transport systems designed to carry lightweight items with ease and efficiency. Our clients can access a versatile range of kitchen lift elevators that adhere to international quality standards, ensuring reliability and durability.

Sigma's advanced kitchen lift elevators are ideal for modern infrastructure in both residential and commercial buildings. These elevators are customized based on their carrying capacity and specific requirements, providing a prompt, economical, and convenient solution for vertical transport. By minimizing manual effort, they save valuable time and labor resources.

Specialized kitchen lift systems from Sigma are designed to transfer food and beverages while maintaining hygiene and freshness. Equipped with ovens or freezers as per the need, they ensure hot or cold food is delivered in pristine condition. Additionally, the growing demand for private residential installations highlights their daily utility in transporting meals, groceries, laundry, or small items effortlessly between floors.

Features at a glance

  • Safe, hygienic, and convenient operation
  • Installation in less than 15 Days.
  • No requirement of machine room.
  • Cabin: Available with or without partitions or compartments
  • Doors: Bi-parting, guillotine, or swing doors as per requirement
  • Operation Type: Easy-to-use push-button controls.
  • Window – Floor Type: Straight up/down travel for efficient functionality.
  • Machine: Option for traction or winding machines based on usage.
  • Kitchen Lift Assembly: Can include freezers and ovens to maintain food temperature.
  • Durable and compact design, suitable for any environment.

Technical Specification

LOAD SHAFT - W SHAFT - D CAR - W CAR - D ENTRANCE
KGS. A B C D E HT.
100 1200 900 700 700 700 800
150 1300 1000 800 800 800 900
200 1400 1100 900 900 900 1000
250 1500 1200 1000 1000 1000 1200

Note: All dimensions are in mm. This is general data and may be changed without notice. All hoist way walls should be a minimum of 230 mm brick or 150 mm RCC. Pit depth should be 750 mm, and the overhead height should be 4400 mm for speeds up to 1.5 m/s.
