Service Lift Elevators Manufacturers
**Service Lift Elevators** are compact and efficient vertical transport systems designed to handle goods and services with ease and precision. Our clients can choose from a wide range of these elevators, built to meet international quality standards, ensuring durability, reliability, and safety.
Sigma's advanced **Service Lift Elevators** are perfect for modern infrastructure in commercial, industrial, and residential buildings. These elevators are customized according to specific load capacities and operational requirements, offering an economical and efficient solution for transporting goods and services across multiple floors.
Specialized systems from Sigma are built to manage a variety of goods, from heavy-duty equipment to delicate items, while ensuring smooth and safe operation. With advanced safety features and seamless performance, they are an ideal choice for factories, hotels, restaurants, hospitals, and retail spaces. Furthermore, their growing popularity in residential spaces highlights their usefulness in transporting groceries, laundry, or other essential items effortlessly between floors.
Features at a glance
- Safe, reliable, and convenient operation.
- Installation in less than 20 days.
- Does not require a dedicated machine room.
- Cabin: Flexible designs available with or without partitions, tailored for specific goods and service needs.
- Doors: Options include bi-parting, collapsible, or automatic sliding doors.
- Operation Type: User-friendly push-button or advanced touch-panel controls.
- Travel Type: Smooth and efficient vertical transport with straight up/down movement.
- Machine: Offered with traction or hydraulic drive systems for maximum adaptability.
- Load Capacity: Customizable configurations ranging from 100 kg to 2000 kg.
- Space-efficient and robust design ideal for industrial, commercial, and residential use.
Technical Specification
LOAD | SHAFT - W | SHAFT - D | CAR - W | CAR - D | ENTRANCE | |
---|---|---|---|---|---|---|
KGS. | A | B | C | D | E | HT. |
300 | 1400 | 1200 | 900 | 1000 | 800 | 1900 |
500 | 1600 | 1500 | 1100 | 1200 | 1100 | 2000 |
750 | 1800 | 1600 | 1300 | 1300 | 1200 | 2100 |
1000 | 2000 | 1800 | 1500 | 1500 | 1400 | 2200 |
1500 | 2400 | 2000 | 1800 | 1800 | 1600 | 2300 |
Note: All dimensions are in mm. This is general data and may be subject to change without prior notice. Hoist way walls should be a minimum of 230 mm brick or 150 mm RCC. Pit depth should be 1000 mm, and overhead height should be 4600 mm for speeds up to 1.5 m/s.
